Carprog Read Opel ECU Data Knowledage

This article show some knowledge about Carprog Opel ECU reading,include:how to connect carprog to different Opel ECU,supported ECU type.



OPEL login reader from motor hybrid ECU. Works by OBDII connector using cable A1, or removed from car using cable A15. On-table connection wiring diagram you can find in user manual.

This CarProg Opel ECU reader you can use in these cases:



Use it like Opel security code reader by OBDII for transponder key programming. In this case you don’t need call dealer for get security code or remove immobilizer to read it manually. For key programming use any key learning tool – TECH 2, AD100 OP-COM or any other;



Use it for used motor ECU repair, reset Engine Control Module and programming. ECU security code is necessary to set back the Engine Control Module to its factory default state. Prior to replace, you have to reset it back to its factory default state. In this way, you can install it into another car. With TECH2 or other equipment you can do this work, but always you need used motor ECU security code (you can read it with CarProg) and car immobilizer security code (remove immobiliser and use TMS370 programmer to read it). Each factory default state Engine ECU has some limited running time, without immobiliser (max 10 attempts);



Carprog Related Contents:

Carprog Software Free Download

Carprog Software Installation Guide



Carprog Supported cars:

Bosch ME 1.5.5 Agila 1.0, 1.2 2000-2005

Astra 1.2, 1.6,2.0 1998-2001

Corsa 1.0, 1.2,1.4 1997-2000

Corsa 1.0, 1.2 2000-2005

Tigra 1.4, 1.6 1997-2000

Zafira 2.0 2002-2003

Carprog Read Opel ECU Data Knowledage (1)



Siemens Simtec 71 Astra 1.8 2001-2004

Corsa 1.8 2001-2003

Omega 2.2 2000-2003

Vectra 1.8 2000-2003

Zafira 1.8 2001-2003

Carprog Read Opel ECU Data Knowledage (2)



Siemens Simtec 71.1

Carprog Read Opel ECU Data Knowledage (3)



Delphi Delco HDRC Astra 1.7DT 2000-2002

Corsa 1.7DT 2001-2005

Meriva 1.7DT 2003-200

Carprog Read Opel ECU Data Knowledage (4)

Delphi Delco Multec S(F)

Astra 1.4, 1.6 2001-2005

Corsa 1.4, 1.6 2001-2005

Meriva 1.6, 1.8 2003-2005

Vectra 1.6 2000-2005

Zafira 1.6 2001-2005

Carprog Read Opel ECU Data Knowledage (5)





Delphi Delco HSFI 2.0-2.5

Carprog Read Opel ECU Data Knowledage (6)



SIMTEC 71 and SIMTEC 71.1 ECU connection on-table diagram:

Carprog Read Opel ECU Data Knowledage (7) Carprog Read Opel ECU Data Knowledage (8)





BOSCH ME1.55 ECU connection on-table diagram:

Carprog Read Opel ECU Data Knowledage (9) Carprog Read Opel ECU Data Knowledage (10)





DELCO PETROL HSFI 2.x and DIESEL 1.7DT ECU connection on-table diagram:

Carprog Read Opel ECU Data Knowledage (11) Carprog Read Opel ECU Data Knowledage (12)





DELCO PETROL HSFI – C ECU

Carprog Read Opel ECU Data Knowledage (13) Carprog Read Opel ECU Data Knowledage (14)
