Categories: Auto Repair

How to Remove&Install Battery for Mercedes-Benz

This instruction will show you guide on how to quick remove and install battery in 10 minutes for Mercedes-Benz. More Mercedes-Benz cases, please refer to Benz Trouble Repair.

Before you remove battery, please note:

Engage parking brakes

Switch off all electrical consumers

Switch off ignition, remove key/start/stop button

Wear acid-resistant gloves clothing and glasses

Risk of injury to skin and eyes from battery acid or when handing damaged led-acid batteries.



Procedures:

Unclip hood extender for both sides

Adjust to service mode

Unclip clamps and remove air duct

Socket 10mm(Nm6) to remove ground line from negative terminal first

IMPORTANT: remove ground line from negative terminal first

Remove ground line from positive terminal

Remove vent line

Socket 13mm and extender(Nm21)

Magnet bolt and rail

Take out battery

Install battery in reverse order



For more automobile battery case,please refer to:automobile battery repair cases
